Cheap Home made metal DSLR Slider
December 13, 2014, 6:26 pm
made with rails of drawers and perforated metal plates
How to ModRL02 PINs to the GPIO of Raspberry PI
May 4, 2014, 12:11 pm
VCC Pin goes directly to VCC from Rapsberry (Green Wire)
GND goes direclty to GND from Rapsberry (Black Wire)
IN1 goes to the at the junction of first diode (1N4148 ) and resistor (4,7 kOhm) (White...
How to connect GPIO Raspberry PI to 2 relay module (mod2rl)
May 4, 2014, 11:47 am
We have used port P1
Yellow cable is GPIO 17
Black is Ground
Orange is +5 V DC
Voltage regulator to control relay module GPIO 3.3V to 5V
May 4, 2014, 11:47 am
What do you need:
1 Resistor - about 4,7 kilo Ohms
2 Diodes - 1N4148 or similar voltage drop in the forward direction at least 0.7 V/10 mA
A few wires
